Customizable Treeviewer built in react for visualizing hierarchical data

React Treeview

Customizable Treeviewer built in react for visualizing hierarchical data.

Installing

npm install --save react-treeviewer

The fontawesome css file is not included so include it in your webpage:

<link href="https://maxcdn.bootstrapcdn.com/font-awesome/4.6.3/css/font-awesome.min.css" rel="stylesheet" />

Another tree viewer?

There are already multiple solutions out the for viewing hierarchical data but I found all existing libraries to be lacking in some manner. I wanted to be able to customize more than I could with the existing solutions.

Features

  • Customize expand and collapse icons
  • Add custom icons to each node
  • Expand nodes by clicking text if selectable is not true.
  • Draggable nodes.
  • Double Click a node to expand or collapse all the children
  • Test suite with 100% coverage

Coming soon

  • Lazy loading node's children
  • Live Examples

Basic Usage

import TreeView from  'react-treeviewer';
render: () {
    <TreeView
        data={data}
    />


}

TreeView Properties

animation

boolean

Turn animations on/off when expanding or collapsing a node.

--

selectable

boolean

Can nodes be selected? ( Selected nodes get the className: ad-selected-node )

--

onSelect(event, nodeData)

function

Callback executed when a node is selected

--

draggable

boolean

Can nodes be dragged?

--

onDrag(event, nodeData), onDragStart(event, nodeData), onDragEnd(event, nodeData)

functions

Callback functions associated with dragging a node.

--

onExpand(event, nodeData)

function

Callback function executed when a node is expanded.

--

onCollapse(event, nodeData)

function

Callback function executed when a node is collapsed.

onExpandAll(event, nodeData)

function

Callback function executed when all nodes are expanded or collapsed.

--

checkable

boolean

Adds checkboxes to each node.

--

onCheck(event, nodeData)

function

Callback executed when a node is checked

--

collapsedIcon

string

Fontawesome icon string to represent the collapsed node anchor

--

expandededIcon

string

Fontawesome icon string to represent the expanded node anchor

--

Data format

[{
    id:1,
    text:"Root",
    icon:"folder",
    expanded:false,
    children:[{
        id:3,
        selected: true,
        checked: false,
        text:"Child 1",
        iconObj: {
            name: 'rocket',
            size: '2x',
            spin: true,
            style: { color: 'red' }
        },
        children:[{id:5, text:"Grandchild 1"}]
        }
    ]
}]

Optional data properties

Add properties to each data node for more fine grained control.

icon

string

Fontawesome icon name.

--

iconObj

object

All properties in this object will be passed down to the icon. (This overrides the icon string property if present.)

expanded

boolean

Is the node expanded?

--

selected

boolean

Is the node selected?

--

checked

boolean

Is the node checked?
